P6 Outdoor led advertise screen
Product description
1,high gray design,even in low light loss is not gray,large angle,ensure quality and delicate,high refresh rate to ensure video and photos without a moire phenomenon.
2,horn special structure and material design.
3,low-power low attenuation,long life.
P6 OUTDOOR P6 SMD 3IN1 TECHNICAL PARAMETERS
| Unit Module | Item | Parameter |
| Model Number | P6-8S |
| Module size | 192mm*192mm |
| Pixel pitch | 6mm |
| Pixels Density | 27777pixels /m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD3535 |
| Pixel resolution | 32dots(W)*32 dots(H) |
| Max Power | 22W |
| Module thickness | 22mm |
| Weight | 0.56kg |
| Drive type | Constant drive |
| Scan mode | 1/8scan |
| Port type | hub75 |
| Brightness of white balance | 6000cd/m2 |
| LED Cabinet | Dimension | 768mm*786mm |
| Monomer Module Number | 18pcs |
| Power supply | 5V/60A*3 pcs or 5V40A 4pcs |
| Thermal discharge | fan 1pcs |
| Pixel per cabinet | 96mm*96mm |
| Best viewing distance | 6M～40M |
| Best viewing angle | 160°(W) 120°(H) |
| Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ |
| Relative humidity | 10%-95% |
| Thickness | 125mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 480W/㎡ |
| Max.Power consumption | ≤1200W/㎡ |
| Current | ≤20mA(single LED) |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 |
| Control method | Synchronization |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | ≥1200HZ |
| Grey scale/colors | 4096gray level/16.7M colors |
| MTBF | ≥9000hours |
| Fire rate | Grade one |
| Display Mode | ≥800*600/1024*768 |
Company information
1.Corporate culture:professional innovate be enterprising cooperation double win
2.Mission:to provide professional,leading control system solution for customer to enhance the competitiveness of products and brand and market value.
3.Vision:Make the display more beautiful,more intelligent,to do the word‘s leading brands in the field of LED display control.
4.Value:innovation to enhance the value,quality cast brand,professional achievement customers.
Our service
1. Anything could be customized
Most of our customers are always asking if they could add something from them, or just add their logo on somewhere, our responses are always yes. We could create the screen shape for you, some logo on your product, even could fit your products in it. How amazing that is!
2. We have a professional engineers team
All of them have experienced more than 5 years in the LED display industry. They are specialists, try their best to make your dream come true.
3. Responsible after services
If the product is under the warranty, once it broke, you could replace it with some spare parts, and send the broken part back, we will fix it and resend it to you.
FAQ
Q1: What's the control system do you use?
A: Our standard control system is Linsn or Novastar. Also support other controlling system, like Huidu,Sheenled,Colorlight etc.
Q2: Do you have any certification for LED display?
A: Yes, we have CE,ROHS, certification.
Q3: How about the guarantee of led display?
A: We guarantee all our displays, modules, spare parts for two years.
During this time, we will replace or remand our goods for free if there is something wrong with them.
